Withwave’s infrared filters are designed using a coaxial cable structure and magnetically loaded epoxy absorbers.
It reduces the noise photon flux and unwanted harmonic RF components for superconducting quantum systems.
Filters are rigorously tested and verified using Withwave’s 4 K cryogenic measurement system to ensure reliable performance at extremely low-temperatures.
Features
• Insertion loss less than 1.8 dB at 10 GHz @ 4K (typical)
• Return loss up to 12 GHz better than 15 dB (typical)
• Based on magnetically loaded dielectric absorber
• Eccosorb CR 110
• Impedance: 50 Ω
• Capable of operation at 10 mK
• Connectors: SMA short F on both sides
• Housing Gold Plated OFHC Copper
• Length: 1.4 inches
• Expandable to 8 channels and more as requested
Applications
• Quantum Computing
• Radio Astronomy
• Space Communication
| Part Number | Cut-off Freq. [GHz] | Insertion Loss Typ. [dB] | Return Loss Min [dB] | Connectors RF | Size | Operating Temp. [K] |
|---|---|---|---|---|---|---|
| IRF-K01-S | 1 | 1 | 15 | SMA (F), (F) | 29 mm (L), 9 mm (Dia) | 10 |
| IRF-K02-S | 10 | 5 | 15 | SMA (F), (F) | 47.5 mm (L), 9 mm (Dia) | 10 |
| IRF-S01-S | 1 | 1 | 15 | SMPS (F), (F) | 26 mm (L), 2.9 mm (Dia) | 10 |
| IRF-S02-S | 10 | 3 | 15 | SMPS (F), (F) | 34 mm (L), 2.9 mm (Dia) | 10 |
