Directional Couplers
WithWave’s Directional Couplers offer various options, number of ports, and power handling up to 26.5 GHz.
Features
• Nominal Coupling : 10 ± 1.0 dB
• Directivity : 12 dB (Typ.)
• SMA • 2.92mm
• 50 Ohms
Applications
• Test and Measurement
Products List
Directional Couplers
| Part Number | Freq. Low [GHz] | Freq. High [GHz] | Coupling [dB] | Directivity Typ. [dB] |
Power Input Max. [W] |
Insertion Loss Max. [dB] |
VSWR Primary Typ. [:1] |
Connectors |
|---|---|---|---|---|---|---|---|---|
| BC04200-10-SF | 0.4 | 20 | 10 ±1.0 | 14 | 30 | 1.9 | 1.4 | SMA (f) |
| BC04200-20-SF | 0.4 | 20 | 20 ± 1.2 | 12 | 30 | 1.0 | 1.4 | SMA (f) |
| BC0560-10-SF | 0.5 | 6 | 10 ±1 | 19 | 50 | 1.2 | 1.2 | SMA (f) |
| BC0560-20-SF | 0.5 | 6 | 20 ± 1.0 | 15 | 20 | 0.6 | 1.15 | SMA (f) |
| BC0560-30-SF | 0.5 | 6 | 30 ± 1.0 | 18 | 50 | 0.7 | 1.1 | SMA (f) |
| BC10265-10-3F | 1 | 26.5 | 10 ± 1.2 | 12 | 30 | 1.6 | 1.3 | 3.5mm (f) |
| BC10265-20-3F | 1 | 26.5 | 20 ±1.2 | 13 | 30 | 1.3 | 1.4 | 3.5mm (f) |
| BC10400-10-KF | 1 | 40 | 10 ± 1.25 | 10 | 50 | 2.6 | 1.3 | 2.92 mm (f) |
| BC120180-10-SF | 12 | 18 | 10 ± 1.0 | 15 | 30 | 1.2 | 1.3 | SMA (f) |
| BC20180-10-SF | 2 | 18 | 10 ± 1.0 | 17 | 50 | 1.1 | 1.2 | SMA (f) |
| BC20180-20-SF | 2 | 18 | 20 ± 1.0 | 17 | 50 | 0.5 | 1.2 | SMA (f) |
| BC20180-30-SF | 2 | 18 | 30 ± 1.0 | 14 | 50 | 0.5 | 1.3 | SMA (f) |
| BC4080-30-SF | 4 | 8 | 30 ±1 | 15 | 50 | 0.6 | 1.3 | SMA (f) |
