WithWave’s standard gain horn Antennas operate in the frequency range from 26.5 GHz to 40 GHz.
The gain horn antenna has nominal gain of 17.0 dBi and Horizontal 3 dB beam width of 27.4 degrees and
Vertical 3 dB beam width of 22.1 degrees. This antenna can be rotated to the desired angle by pulling and rotating it.
Features
• Rectangular Waveguide Interface
• Freq. range: 26.5 to 40 GHz
• Nominal Gain: 17 dBi
• Design: Standard Gain Horn
✓ Pattern: Directional
✓ Polarization: Linear
✓ Coaxial interface: 2.92mm (Female)
Applications
• EMI test
• Calibration devices that measure the gain of other antennas
Products List
Antennas
| Model Number | Freq. Low [GHz] | Freq. High [GHz] | Gain [dBi] | 3 dB Horizontal Width [deg] |
3 dB Vertical Width [deg] |
VSWR(:1) Typ. | Connector(s) | Flange Type |
|---|---|---|---|---|---|---|---|---|
| WAKH-01 | 26.5 | 40 | 17~19 | 20 ± 5° | 16 ± 5° | 1.5 | 2.92mm (f) | Square Cover |
| WAKH-02 | 26.5 | 40 | 20 | 1.4 | 2.92mm (f) | Square Cover | ||
| WATH-01 | 275 | 295 | 21 | 10 | 10 | WR3.4 | ||
| WAES-01 | 71 / 81 | 76 / 86 | 30 | WR12 | Slot Array | |||
| WAKP-01 | 24 | 24 | 15 | 2.92mm (f) | Patch Array | |||
| WAEI-01 | 76 | 77 | 17 | WR12 | SIW |
